High-Efficiency Vacuum Belt Dryer for Heat-Sensitive Solid Materials
The ZDG vacuum belt dryer (solid) is a high-performance continuous vacuum drying equipment designed for low-temperature, gentle drying of heat-sensitive solid materials.
This advanced industrial vacuum dryer is widely used in pharmaceutical, food, chemical, and biotechnology industries, ensuring high-quality drying while preserving material color, flavor, and active ingredients.
It is especially suitable for products requiring strict moisture control and high purity standards.
Why Choose ZDG Vacuum Belt Dryer?
Our vacuum belt drying system is engineered for efficiency, stability, and product quality:
- Continuous feeding and discharging under high vacuum
- Low-temperature drying to protect heat-sensitive materials
- Multi-layer belt design for higher capacity
- Independent temperature control for each drying zone
- Energy-efficient operation compared to traditional dryers
- Fully automated control system for stable production
Working Principle of Vacuum Belt Dryer
The vacuum belt dryer (solid) operates by evenly distributing material onto a moving conveyor belt through a specialized feeding system.
Under a controlled vacuum environment:
- Material is transported continuously at uniform speed
- Heating plates below the belt provide precise thermal energy
- Moisture is gently evaporated at low temperature
- Material passes through multiple drying layers
- Final product is cooled, loosened, and discharged automatically
The system ensures efficient heat transfer, minimal thermal degradation, and consistent product quality.
Key Features of ZDG Vacuum Belt Dryer
Continuous Vacuum Drying System
Designed for uninterrupted industrial production with stable performance.
Low Temperature Gentle Drying
Protects sensitive materials such as herbal extracts, pharmaceuticals, and food ingredients.
Multi-Zone Independent Temperature Control
Each drying zone can be adjusted separately for optimal drying conditions.
Energy Efficient Design
Consumes significantly less energy compared to conventional drying systems.
CIP Cleaning System
Built-in cleaning-in-place system ensures hygiene and reduces downtime.
GMP & FDA Compliant Design
Suitable for pharmaceutical and food-grade production environments.
Automated Operation System
Reduces manual labor and improves production efficiency.
Applications of Vacuum Belt Dryer
The ZDG vacuum belt dryer (solid) is widely used in:
- Pharmaceutical Industry: herbal extracts, API drying, biological materials
- Food Industry: fruit powder, vegetable powder, functional foods
- Chemical Industry: heat-sensitive chemical solids
- Biotechnology: fermentation products and bioactive materials
- Health Products: nutritional supplements and extracts
Technical Specifications
| Model | ZDG04-2 | ZDG06-3 | ZDG15-3 | ZDG30-4 | ZDG50-4 | ZDG80-5 | ZDG100-6 | ZDG120-7 | ZDG160-8 | ZDG180-10 | ZDG200-10 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Heat Exchange Area (m²) | 4 | 6 | 15 | 30 | 50 | 80 | 100 | 120 | 160 | 186 | 200 |
| Main Machine Diameter (mm) | 1000 | 1200 | 1400 | 1700 | 1800 | 2000 | 2200 | 2400 | 2500 | 2800 | 3000 |
| Length (mm) | 5000 | 6000 | 9000 | 12000 | 15000 | 15000 | 16000 | 16000 | 16000 | 16000 | 16000 |
| Belt Layers | 2 | 3 | 3 | 4 | 4 | 5 | 6 | 7 | 8 | 10 | 10 |
| Feed Temperature | ≤60°C (all models) | ||||||||||
| Final Moisture | ≤3% | ||||||||||
| Belt Speed | Adjustable according to process | ||||||||||
| CIP Pressure | 0.3–1 MPa |
Advantages of Vacuum Belt Drying Technology
- Preserves product quality and active ingredients
- Suitable for heat-sensitive and fragile materials
- Continuous industrial-scale production
- Stable moisture control and uniform drying
- Reduced energy consumption and operating cost
Get a Quote for ZDG Vacuum Belt Dryer
Upgrade your production with a reliable vacuum belt dryer system designed for efficiency, hygiene, and high-quality drying results.
👉 Contact us today for pricing, customization options, and technical consultation.
